Housewatch/HWC Product Guide 2015

88 / 96

88
COMMERCIALPRODUCTS
Product Guide 2015 I
55-464 (Surface Mount)
360° PRESENCE DETECTOR INDOOR/OUTDOOR
Description Colour Model
Flush Mount Detector White 55-463
Surface Mount Detector White 55-464
• Multi-function
- On/Off
- 1 – 10V dimming
- Time adjustment
- Light sensing
55-463 (Flush Mount)
55-211
ø110mm
52mm
62.5mm 110mm
ø110mm ø106mm
52mm
70mm
52mm
99mm
75mm
Mounting Flush
Sensor Adjustment Adjustable with Lens Shield
Sensor Type High Frequency 5.8GHz
Detection Range 8m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 10 sec to 30 mins
Lux Setting (Lux) 10 to 2000
Load Incandescent Lamp: max. 2000W
AC Halogen Lamp: max. 1000W
LV Halogen Lamp: max. 1000VA/600W (traditional)
max. 1000VA/900W (electronic)
Fluorescent Lamp: max. 1000VA/600W (uncompensated)
LED Lamp: max. 500VA/400W
Electronic Ballast: max. 100mA (50 Pieces)
Voltage 230v ± 10% 50 Hz
Operating Temperature 0˚C to + 45˚C Indoor usage -20 ˚C to +45˚C
Environmental Protection IP40 Flush Mount with power box cap
IP54 Surface Mount with junction box
Cable –
TECHNICAL DATA
SENSORS
PAR38
• Cutout diameter: 70mm
• ABS construction
• Programmed by remote control
(55-211 optional accessory)
PAR38
