Housewatch/HWC Product Guide 2015

91 / 96

91
COMMERCIALPRODUCTS
Product Guide 2015 I
HIGH BAY PRESENCE DETECTOR
Description Colour Model
High Bay Presence Detector White 55-618
55-618
55-212
88mm
62mm
121mm
117mm
ø63mm
88mm
62mm
117mm
ø63mm
Mounting Side
Sensor Adjustment Fixed
Sensor Type High Frequency 5.8GHz
Detection Range 6m Diameter at 10m High
Detection Angle 360˚
Time on Adjustment 5 sec to 30 mins
Lux Setting (Lux) 5 to 2000
Load Incandescent Lamp: max. 2000W
AC Halogen Lamp: max. 1000W
LV Halogen Lamp: max. 1000VA/600W
Fluorescent Lamp: max. 900VA/100˚F
LED Lamp: max. 500VA/400W
Voltage 220 – 240V 50 Hz
Operating Temperature -20˚C to + 50˚C
Environmental Protection IP44
Cable –
TECHNICAL DATA
SENSORS
PAR38 PAR38
• Multi-function
- On/Off
- Time adjustment
- Light sensing
• ABS construction
• Programmed by remote control
(55-211 optional accessory)
