90 / 96
90
COMMERCIALPRODUCTS
Product Guide 2015
I
www.housewatch.com.auHIGH FREQUENCY PRESENCE DETECTOR
Description
Colour
Model
Flush/Surface Mount Detector
White
55-615
55-615
55-211
ø78mm
60mm
49mm
92mm
68mm
Mounting
Flush
Sensor Adjustment
Pivot Down
Sensor Type
High Frequency 5.8GHz
Detection Range
8m Diameter at 2.5m High
Detection Angle
180
˚
Time on Adjustment
10 sec to 30 mins
Lux Setting (Lux)
0 to 2000
Load
Incandescent Lamp: max. 2000W
AC Halogen Lamp: max. 1000W
LV Halogen Lamp: max. 1000VA/600W
Fluorescent Lamp: max. 900VA/100
˚
F
LED Lamp:
max. 500VA/400W
Voltage
230V ± 10% 50 Hz
Operating Temperature
0
˚
C to + 45
˚
C
Environmental Protection
IP40 Flush Mount with power box cap
IP54 Surface Mount with junction box
Cable
–
TECHNICAL DATA
SENSORS
PAR38
PAR38
• Multi-function
- On/Off
- Time adjustment
- Light sensing
• Cutout diameter: 70mm
• ABS construction
• Programmed by remote control
(55-211 optional accessory)
