Product Guide 2015 I
360˚ MINI PRESENCE DETECTOR WITH DIMMING CONTROL
55-211
Description Colour Model
Mini Flush Mount Detector White 55-453
55-453
90mm
83mm
ø38mm
Mounting Flush
Sensor Adjustment Adjustable with Lens Shield
Sensor Type High Frequency 5.8GHz
Detection Range 8m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 10 sec to 30 mins
Lux Setting (Lux) 10 to 2000
Load Incandescent Lamp: max. 2000W
AC Halogen Lamp: max. 1000W
LV Halogen Lamp: max. 1000VA/600W (traditional)
max. 1000VA/900W (electronic)
Fluorescent Lamp: max. 1000VA/600W (uncompensated)
Electronic Ballast: max. 100mA (50 Pieces)
Voltage 230v ± 10% 50 Hz
Operating Temperature 0˚C to + 45˚C
Environmental Protection IP 40 Detector, IP20 Power Box
Power Consumption 0.5W
TECHNICAL DATA
SENSORS
PAR38
Actual Size
Power Box
• Multi-function
- On/Off
- 1 to 10V dimming
- Time adjustment
- Light sensing
• Cutout diameter: 33mm
• ABS construction
• Programmed by remote control
(55-211 optional accessory)
PAR38
