Housewatch/HWC Product Guide 2015

93 / 96

93
COMMERCIALPRODUCTS
Product Guide 2015 I
SENSORS DALI
360° PRESENCE DETECTOR INDOOR/OUTDOOR
55-384I
TECHNICAL DATA
Description Colour Model
Flush Mount Detector White 55-384I
Flush Mount Detector, Slave Max. 10 Pieces White 55-384IS
ø100mm
80mm
65mm
ø100mm
55-213
Mounting Flush
Sensor Adjustment Adjustable with Len Shield
Sensor Type Passive IR
Detection Range 8m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 1 min to 60 mins
Lux Setting (Lux) Adjustable from approx. 5 Lux to 2000 Lux
Load 2 channels (DA1 + DA2)
Electronic ballast (25 Pieces)
LED drivers (25 Pieces)
Voltage 230v ± 10% 50 Hz
Operating Temperature 0˚C to + 45˚C Indoor Usage -20 ˚C to +45˚C
Environmental Protection IP40 flush mount with power box cap
Power Consumption 0.5W
PAR38
• Multi-function
- On/Off
- DALI dimming
- Time adjustment
- Light sensing
• Stand-by mode
• Cutout diameter: 68mm
• ABS construction
• Programmed by remote control
(55-213 optional accessory)
PAR38
