Product Guide 2015 I
360° PRESENCE DETECTOR WITH DALI CONTROL
55-408I
TECHNICAL DATA
Description Colour Model
Flush Mount Detector White 55-408I
Flush Mount Detector Slave, 10 Pieces White 55-408IS
SENSORS DALI
65mm
ø75mm
103mm
14mm
65mm
ø75mm
103mm
14mm
55-213
Mounting Flush
Sensor Adjustment Adjustable with Lens Shield
Sensor Type Passive IR
Detection Range 8m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 1 min to 60 mins
Lux Setting (Lux) Adjustable from approx. 5 Lux to 2000 Lux
Load LED drivers (50 pieces)
DALI ballast (50 pieces)
Voltage 230v ± 10% 50 Hz
Operating Temperature 0˚C to + 45˚C Indoor Usage -20˚C to +45˚C
Environmental Protection IP40 Flush Mount with Power Box Cap
Power Consumption 0.5W
PAR38
• Multi-function
- On/Off
- DALI dimming
- Time Adjustment
- Light sensing
• Stand-by mode
• Cutout diameter: 68mm
• ABS construction
• Programmed by remote control
(55-213 optional accessory)
