COMMERCIALPRODUCTS
Product Guide 2015 I
Description Colour Model
16W LED Solar Floodlight Black 56-129
56-129
16W LED SOLAR FLOODLIGHT WITH PIR
TECHNICAL DATA
Mounting Wall/ceiling
Sensor Adjustment Fixed
Sensor Type Passive IR
Detection Range 10 to12m
Detection Angle 120˚
Time on Adjustment Depends on battery condition
Lux Setting (Lux) 0 to 2000
Light Intensity (Lumens) 1200
Colour Temperature 5400K
SMD 24 LED Array
Voltage 4.2V DC
Operating Temperature -20˚ C to +60˚ C
Environmental Protection IP65
Cable –
SOLAR FLOODLIGHTS
• Lithium battery
• Battery condition indicator
• Battery charging time: 4 to 8 hrs
• Digital charging controller
• Battery capacity: 12Ah
• 36W solar panel
• Mounting brackets
• Aluminium & polycarbonate construction
• Stainless steel screws
PAR38 PAR38 PAR38 PAR38
PAR38
Battery Condition 100%
Battery Condition 60%
Battery Condition 35%
PIR function only
Operates on Min Light from Dusk till Dawn
Operates on Max Light for 20 secs after PIR detection
Operates on Med Light from Dusk till Dawn
Operates on Max Light for 30 secs after PIR detection
Operates on Max Light for 10 secs after PIR detection
157mm
284mm
187mm
195mm
155mm
125
110mm
50mm
70mm
210mm
