Product Guide 2015 I 49
SECURITYLIGHTING&SENSORS
360° DUAL TECHNOLOGY SURFACE MOUNT PRESENCE DETECTOR
55-456
SENSORS
Description Colour Model
Ultrasonic Surface Mount Detector White 55-456
ø111.5mm
Detector with
ø111.5mm
Detector with JB-46 junction box (optional)
52mm
67mm
67mm
Mounting Surface Mount
Sensor Adjustment Adjustable with Lens Shield
Sensor Type Passive IR /Ultrasonic
Detection Range PIR 8m Diameter, Ultrasonic 10m x 16m (Oval Shape)
Detection Angle 360˚
Time on Adjustment 5 sec to 30 mins, Test & 1s
Lux Setting (Lux) 10 to 1000
Load - 2000W max. for Incandescent Light
- 1000W max. for AC Halogen Light
- 1000VA/600W max. for Low Voltage Halogen Light
(traditional)
- 1000VA/900W max. for Low Voltage Halogen Light
(electronic)
- 900VA/100˚ F for Fluorescent Light (uncompensated)
Voltage 230V +/- 10% AC 50/60 Hz
Operating Temperature 0˚C to to +45˚C
Environmental Protection IP20
Power Consumption –
TECHNICAL DATA
PAR38
• Multi-function • Dual technology sensor
- On/Off • Cutout diameter: 56mm
- Time adjustment • ABS construction
- Light sensing
PAR38
