SECURITYLIGHTING&SENSORS
360˚ DUAL RELAY PRESENCE DETECTOR
Description Colour Model
Dual Relay, Flush Mount Detector White 55-408
55-408
65mm
ø75mm
103mm
14mm
65 m
ø75mm
103mm
14mm
Mounting Flush
Sensor Adjustment Adjustable with Lens Shield
Sensor Type Passive IR
Detection Range 8m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 5 sec to 30 mins – Timer 1 for Lighting
10 sec to 60 mins – Timer 2 for HVAC
Lux Setting (Lux) 0 to 2000
Load - 2000W max. for Incandescent Light
- 1000W max. for AC Halogen Light
- 1000VA/600W max. for Low Voltage Halogen Light
- 900VA/100˚ F for Fluorescent Light
- 600VA (400W) Max. for Energy Saving Lamp (CFL & PL Lamps)
Voltage 240V AC 50Hz
Operating Temperature 0˚C to to +45˚C
Environmental Protection IP44
Cable –
TECHNICAL DATA
PAR38
• Multi-function
- On/Off
- Time adjustment
- Light sensing
• Two relays to control lighting & HVAC devices
• Cutout diameter: 68mm
• ABS construction
SENSORS
PAR38
