Housewatch/HWC Product Guide 2015

45 / 96

Product Guide 2015 I 45
SECURITYLIGHTING&SENSORS
Actual Size
SENSORS
85mm
70mm
70mm
ø50mm
35mm
85m
70mm
ø50mm
360° MINI PRESENCE DETECTOR
55-368
TECHNICAL DATA
Description Colour Model
360˚ Mini Presence Detector White 55-368
55-213
• Multi-function
- On/Off
- Time adjustment
- Light sensing
Mounting Flush
Sensor Adjustment Adjustable with Lens Shields
Sensor Type Passive IR
Detection Range Up to 6m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 5 sec to 30 min
Lux Setting (Lux) 5 to 2000
Load - 2000W max. for Incandescent Light
- 1000W max. for Halogen Light
- 600VA max. for Low Voltage Halogen Light
- 900VA/100˚ F for Fluorescent Light (CFL & PL Lamps)
- 600VA (Max) 400W for Energy Saving CFL Lamp
- 500VA/400W Max. for LED Lamp
Operating Temperature 0˚C to +45˚C
Environmental Protection IP55
Power Consumption 0.5W
PAR38
• Cutout diameter: 38mm
• ABS construction
• Programmed by remote control
(55-213 optional accessory)
PAR38
