Housewatch/HWC Product Guide 2015

42 / 96

Product Guide 2015 I 42
SECURITYLIGHTING&SENSORS
TWILIGHT SWITCH
Description Colour Model
Twilight Switch, 10A White 55-055
• Suitable for lighting and HVAC automation
• 60 sec light on/off delay for preventing false triggering
• Function modes: holiday, Lux learning and test mode
• Lux and time control
55-055
SENSORS
80mm 40mm
130mm
80mm 40mm
130mm
Mounting Wall or Optional Corner Mount Bracket,
(Model No. 55-056)
Sensor Adjustment Fixed
Sensor Type Passive IR
Detection Range 12m
Detection Angle 110˚
Time on Adjustment 5 Precise Time Settings 1h, 2h, 4h, 6h, 8h
Lux Setting (Lux) 5 to 500
Load - 10A for Lighting
- 2000W Incandescent Lamp
- 900VA/100 ˚F Fluorescent Lamp
- 1000W AC Halogen Lamp
- 1000VA LV Halogen Lamp
Voltage 230V +/- 10% 50/60Hz
Operating Temperature -25˚C to +50˚C
Environmental Protection IP54
Cable –
TECHNICAL DATA
PAR38 PAR38
