Housewatch/HWC Product Guide 2015

38 / 96

Product Guide 2015 I 38
SECURITYLIGHTING&SENSORS
TECHNICAL DATA
Description Colour Model
Stand Alone Sensor, 300 Degrees White 55-107
55-107
STAND ALONE SENSOR, 30O DEGREES
• Manual override
• Time, Lux, distance adjustment
• Energy efficient less than 0.25W in standby mode
SENSORS
86mm
101mm
199mm
101mm
199mm
Mounting Wall/Ceiling
Sensor Type Passive IR
Detection Range 12m to 14m at 2.5m High
Detection Angle 300˚
Time on Adjustment 6 sec to 12 mins
Lux Setting (Lux) 0 to 2000
Load - 1000W (Max) for Incandescent Lamp
- 400VA (Max) for Low voltage Halogen Lamp
- 500W (Max for Halogen Lights
- 400VA (Max) Uncompensated for Fluorescent lamp
Voltage 220 to 240V 50Hz
Operating Temperature -20˚C to +45˚C
Environmental Protection IP55
Cable –
PAR38 PAR38
• Stainless steel screws
• ABS construction
