Housewatch/HWC Product Guide 2015

44 / 96

Product Guide 2015 I 44
SECURITYLIGHTING&SENSORS
360˚ MINI FLUSH SENSOR
Description Colour Model
Mini Flush Mount Sensor White 55-451
• Omni-directional dual element sensor
• Cutout diameter: 33mm
• ABS construction
55-451
Actual Size
SENSORS
80mm
85mm
ø38mm
163mm
26
N N L L
LD1D2
80mm
85mm
ø38mm
163mm
28mm 26mm
Mounting Flush
Sensor Adjustment Fixed
Sensor Type Passive IR
Detection Range 5.6m to 11m Diameter at 2.5m High
Detection Angle 360˚
Time on Adjustment 1 sec to 15 mins, Precise
Lux Setting (Lux) 0 to 2000
Load - 2000W max. for Incandescent Light
- 1000W max. for Halogen Light
- 600VA max. for Low Voltage Halogen Light
- 900VA/100˚ F for Fluorescent Light (CFL & PL Lamps)
- 600VA (Max) 400W for Energy Saving CFL Lamp
- 500VA/400W Max. for LED Lamp
Voltage 240V AC 50Hz
Operating Temperature 0˚C to +45˚C
Environmental Protection IP40
Power Consumption –
TECHNICAL DATA
• Multi-function
- On/Off
- Time adjustment
- Light sensing
Power Box
PAR38 PAR38
