www.housewatch.com.auKEYPAD OUTDOOR WEATHERPROOF
TECHNICAL DATA
Description
Colour
Model
Standalone Keypad, 500 users, Backlit, Weatherproof
Charcoal
20-962
Operating Voltage Range
12 to 24V DC (From a Regulated Power Supply
16 to 24V AC (From a Transformer)
Relay Outputs
Lock Strike: Form C, 5 Amp Auxiliary: Form C, 5 Amp
Inputs
N.O., Dry Contact Auxiliary (In/Monitor) N.O., Dry Contact
LEDs
Two Tri-Coloured LEDs with Additional LED Control Feature
Tamper Output
Open Collector, Active Low 32mA Max Sink Current
PIN Codes
8 Formats Supported; From Single Key Up to 8 Digit PIN Codes
LED Control Input
Dry Contact, Normally Open
Reader Inputs
Supports 2 Standard Wiegand 26 Bit Readers/Pin Keypads
3 Security Modes
Three Modes Of Operation; Normal/Bypass/Secure
Audio/Visual
Built in Sounder (Bell, Chime, Siren)
Dimensions
44 (w) x 135 (h) x 28 (d) mm
• IP65 and UV resistant
• Up to 500 users can be coded using smart enroll and delete technology
• Three user levels: Normal (single pin), Secure (dual pin) and Master
• Pin code length: 4 to 8 digits
• Ten auxiliary modes including door ajar, forced door and door monitor
ACCESSORIES
Description
Model
12V DC Power Supply
01-121
Solenoid Gate Release
10-110
01-121
20-962
KEYPADS
135mm
40mm
