ALARMSYSTEMS
Product Guide 2015
I
www.housewatch.com.auDOOR BEAMS
DOOR BEAM PARADOOR
TECHNICAL DATA
Description
Colour
Model
Paradoor Detector, Curtain Beam, Timer
White
45-250
Paradoor Detector Kit with 12V DC Power Supply, Buzzer
White
45-300
Sensor
Dual Element, Low Noise, High Response
Processing
Threshold, APSO, Automatic Temperature Compensation
(Metal Shielding)
Detection Speed
25mA
Power Input
9 to 16V DC or 20-27V DC, 18mA Maximum
Lens
Lodiff Segment Real Full Curtain Fresnel Lens
Coverage
Front View – 40°, 1.5m at 5ft, 4.5m at 15ft
Side View 2.1m for Card Access, 6.6m for Security
Zones
1 (Full Curtain), 2 Positions
Alarm/Signal
Green LED – 0.5 sec to 25 sec adjustable
Alarm Signal Output
0.15/28V, 2A/28VDC Transistor Open Collector, Selectable to
N.C. or N.O. Operation
Anti Tamper Switch
0.15A, 28V DC, Opens When Cover Removed
Operating Temp
-10
˚
C to +50
˚
C
Humidity
95% Maximum
• Unique dual element rectangular sensor
• Narrow full curtain beam
• Can detect movements caused by a hand sized object up to 2.1m and movements of a human
body up to 6.6m
45-250
45-300
93mm
115mm
