ALARMSYSTEMS
Product Guide 2015 I
TRANSMITTER & RECEIVER
TECHNICAL DATA
Description Colour Model
Mini Handheld Transmitter, 12V DC, IP40, TF-69 Dark Grey 55-069
Receiver, Down Light Style, 6A, IP20, RF-150D White 55-070
TRANSMITTER
Transmission Range 50m in Open Air
IP Rating IP40
Rated Voltage 12V DC (A23 Battery)
Transmission Frequency 433.92MH
Channel Four to 64 Combinations
Operation Temperature 0˚C to +45˚C
RECEIVER
Transmission Range 50m in Open Air
IP Rating IP20
Rated Voltage 240V 50Hz
Switching Load - 6A (Max) Voltage Free Contact
- Energy Saving Lamp (CFL): 250VA (150W) Max
- (Includes CFL & PL Lamp), LED Lamp: Max: 250VA/200W
Transmission Frequency 433.92MHz
Modulation ASK (Amplitude Shifting Keyring)
Cut Out 63mm
• Suitable for outdoor or indoor lighting, tennis courts, sheds, garden lighting, pool lights, pool
pumps, venetian blind, ventilator
• Wireless home automation
• Able to control 64 different lighting applications
55-069 55-070
TRANSMITTERS & RECEIVERS
45mm
70mm
80mm 4
80mm
80mm 45mm
80mm 80mm
PAR38
