ALARMSYSTEMS
Product Guide 2015 I
FOUR CHANNEL RF TRANSMITTER & RECEIVER
Description Colour Model
Four Channel RF Transmitter with Key Chain, 12V DC Black 75-063
Four Channel Receiver, 433.92MHz Black 75-064
75-063 Features
• Operates up to 150 metres
• Over 68 billion possible codes
• Includes 12V DC alkaline battery
• Dimensions: 60mm x 35mm x 15mm
75-064 Features
• One Channel. 433.92MHz
• Small size (80 x 65 x 19mm)
• Control garage doors, etc.
• LED shows RF reception program status
• Mode switches for easy transmitter learning
75-063
75-063
75-064
TRANSMITTERS & RECEIVERS
75-064
TECHNICAL DATA
Operating Distance 150m
Operating Voltage 11 to 24V AC/DC
Current Draw 8mA at 12V DC Standby, 45mA at 12V DC LED Flashing
Memory Capacity 15 Transmitter Button Codes per Channel
Receiver Output Modes Timed Momentary (1, 2, 3, 4, 5, 10, 30, 60 sec)
Toggle (ON/OFF), Latched, Continuous
Receiver Outputs Form C Dry Relay Contact (N.O/N.C/Com);
max 10 Amp and 24VDC
Operating Frequency 433.92MHz
RF Codes 18 Quintillion Code bump
Dimensions 135 x 111 x 28mm
Operating Temperature 20˚ to 72˚C
55mm
33mm
106mm
130mm
