CLOSEDCIRCUITTV
Product Guide 2015 I
17" COLOUR CCTV MONITOR
TECHNICAL DATA
Description Colour Model
17 inch Colour CCTV Monitor Black 96-105
Active Display Area 338(w) x 270mm(h)
Display Mode 4:3
LCD Type TFT-LCD
Resolution 1280 x 1024
Display Colour 16.7m
Pixel Pitch (mm) 0.264 (horizontal) x 0.264 (vertical)
Brightness (nits) 300 cd/m 2
Contrast Ratio 1000:1
Viewing Angle 160 (horizontal)/160 (vertical)
V-Frequency 60 Hz
Operating Temperature -20˚C to 70˚C
Inputs VGA (1), HDMI (1), Composite (BNC x1)
System PAL/NTSC/SECAM
3D Comb Filter Yes
Video Comb Filter Yes
Power Input DC 12V/4A
Maximum in Operation ≤ 35W (Max)
96-105
• 1280 x 1024 resolution
• Wide viewing angle
• 3.7ms response time
• VGA/HDMI/BNC input
• H.264 main profile video compression format
• Dual encoding streams
• Web and mobile phone monitoring support
• HDVGA and BNC simultaneous output
MONITORS
432mm
368mm
435mm
