ALARMSYSTEMS
Product Guide 2015
I
www.housewatch.com.auINFRARED DETECTORS
PASSIVE INFRARED DETECTOR
TECHNICAL DATA
Description
Colour
Model
Pet Immune Detector up to 25kg, 18m
White
50-042
Power Input
8.2 to 16V DC
Current Draw
Standby: 8mA (±5%)
Active: 10mA (±5%)
Detection Method
Quad (Four Element) PIR
Range
18m with Wide Angle Lens
Alarm Output
N.C 28V DC 0.1A with 27 Ohm Series Protection Resistor
Tamper Switch
N.C 28V DC 0.1A with 10 Ohm Series Protection Resistor
Dimensions
92 x 59 x 37mm
• Temperature compensation
• Variable pulse width adjustment
• Sensitivity adjustment
• Immunity to animals up to 25kg
50-042
55mm
90mm
