Housewatch/HWC Product Guide 2015

14 / 96

Product Guide 2015 I 14
SECURITYLIGHTING&SENSORS
59-101
Description Colour Model
Bulkhead 12W with Motion Sensor Black 59-101
Bulkhead 12W with Motion Sensor White 59-104
• Provides continuous low level courtesy
light from dusk till dawn
• Manual override
• Timing & Lux adjustment
• Stainless steel screws
• Polycarbonate construction
• Portrait mounting
TECHNICAL DATA
Mounting Wall/ceiling
Sensor Adjustment Fixed
Sensor Type Passive IR
Detection Range 8 to12m
Detection Angle 120˚
Time on Adjustment 5 sec to 5 mins
Lux Setting (Lux) 5 to 2000 (12W high & 3W standby mode)
Light Intensity (Lumens) 1200
Colour Temperature 5700K
SMD 60 LED Array
Voltage 230V AC 50Hz
Operating Temperature -32˚ C to +60˚ C
Environmental Protection IP65
Cable –
BULKHEAD 12WWITH MOTION SENSOR
155mm
260mm
260mm
155mm
78m
50mm
155mm
260mm
260mm
155mm
78mm
50mm
PAR38 PAR38 PAR38
SECURITY LIGHTING
